Three Roll Planetary Axis With Pre Bending/Pre Punching(Section Bending machine)

Overview

The Three Roll Planetary Axis With Pre Bending/Pre Punching (Section Bending Machine) is a versatile and efficient solution for bending metal sections, profiles, and structural components into accurate curved shapes. Designed for industrial applications, this machine combines a three-roll planetary axis system with pre-bending and pre-punching capabilities, depending on the machine's configuration.

The three-roll planetary mechanism helps guide and shape metal sections during the bending process, supporting the production of circular, curved, and customized profiles. The pre-bending function helps reduce flat or straight portions at the ends of the workpiece, improving the quality of the finished component and minimizing material waste.

The pre-punching capability can support the preparation of sections with required holes or openings before further processing, where this function is included in the machine setup. These operations help improve workflow efficiency and reduce the need for separate processing steps.

Built with a strong and durable structure, the machine is designed to provide stability, reliable performance, and consistent bending results. It can be used for compatible metal profiles and sections, such as angles, channels, flats, and other structural shapes, depending on the machine's tooling and capacity.

The Three Roll Planetary Axis With Pre Bending/Pre Punching Section Bending Machine is suitable for steel fabrication workshops, construction industries, engineering units, infrastructure projects, and structural metal manufacturing. It helps manufacturers produce curved components for frames, supports, arches, and other fabricated structures.

With its practical design and versatile bending capabilities, this machine offers an effective solution for businesses seeking accuracy, productivity, and dependable performance in section bending operations. Proper operation and regular maintenance help ensure consistent results and long-term service life.

--------------------------------------------------------------------------------------------------------------------

Standard Features

1. All Rolls Manufactured From Alloy Steel Material

2. Both The Top And Bottom Rolls Are Positively Driven by Inline Mounted Planetary Gear Box And Hydraulic Motor.

3. Possible To Place Side Roll In Inclined Position For Conical Rolling.

Optional Features

--------------------------------------------------------------------------------------------------------------------

1. A Special Alloy Steel Material For Hardened Rolls. Hardness Up To 52-60 Rc.

2. All 3 Rolls (Top And Side Rolls) / All 4 Rolls (Top, Bottom And Side Rolls) Are Positively Driven.

3. A Separate Cone Bending Attachment Can Be Provided For Narrow Diameter Cone Forming.

4. Provision For Section Rolling.

5. Section Bending Dies.

6. Overhead Support.

7. Lateral Support.

8. Auto Plate Squaring Reference Stopper.

9. Til Table Top Roll.

10. Automatic Roll Speed Compensation.
